| Parameter | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 650 | 715 |
| Power Rating (kW) | 520 | 572 |
| Frequency (Hz) | 50 | |
| Engine Model | 6M33D633E200 | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BWC715 | BWC715S |
|---|---|---|
| Type | Open | Silent |
| Length (L) mm | 3800 | 4300 |
| Width (W) mm | 1740 | 1600 |
| Height (H) mm | 2745 | 2250 |
| Tank Capacity (L) | 1196 | 1196 |
| Engine Model & Manufacturer | 6M33D633E200 (WEICHAI) |
| Emission Certification | ---- |
| Number of Cylinders | 6 |
| Cylinder Arrangement | In-line |
| Cycle | L-Type |
| Aspiration | Turbocharging and Intercooling |
| Bore x Stroke | 150 x 185 mm |
| Cubic Capacity | 19.6 L |
| Compression Ratio | 15.0:1 |
| Prime Power / Speed | 575 kW / 1500 rpm |
| Standby Power / Speed | 639 kW / 1500 rpm |
| Governor Type | Mechanical Pump |
| Cooling System | Force Water Cooling Cycle |
| Transient Frequency Deviation | -0.833333333 |
| Total Lubrication System Capacity | 61 L |
| Coolant Capacity (Engine Only) | 43.93 L |
| Fuel Consumption @ 100% Load | 575 g/kWh @ 1500 rpm |
| Starter Motor | DC 24V |
| Charge Alternator | DC 24V |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-354F |
| Alternator Rated Power | 520kW / 650kVA |
| Rated Voltage (V) | 230V / 400V |
| Rated Frequency | 50Hz |
| Connecting Type | 3 Phase and 4 Wire |
| Number of Bearings | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H Class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Transient State Voltage | ≤-15%~+20% |
