| Specification | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 125 | 138 |
| Power Rating (kW) | 100 | 110 |
| Frequency (Hz) | 50 | |
| Engine Model | LR6A3L-D | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BYT138 (Open Type) | BYT138S (Silent Type) |
|---|---|---|
| Length (L) mm | 2350 | 2950 |
| Width (W) mm | 800 | 1040 |
| Height (H) mm | 1580 | 1480 |
| Tank Capacity (L) | 230 | 230 |
| Engine Model & Manufacturer | LR6A3L-D (YTO) |
| No. of Cylinders | 6 |
| Cylinder Arrangement | In-line |
| Cycle | 4 stroke, compression ignition |
| Method of Air Aspiration | Turbocharged with air-air intercooler |
| Cooling Medium | Liquid |
| Bore | 105 mm |
| Stroke | 125 mm |
| Compression Ratio | 17.0:1 |
| Cubic Capacity | 6.49 L |
| Dry Engine Weight | 665 kg |
| Dimension (L*W*H) | 1081*1456*708 |
| Direction of Rotation | Anti-clockwise viewed on flywheel |
| Governed Engine Speed | 1500 |
| Firing Order | 1-3-4-2 (1cyl furthest from flywheel) |
| Standby Power | 122 |
| Adaptive Power Station (kW) | 110 |
| Steady State Speed Stability at Constant Load | 3% |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-274D |
| Alternator Rated Power | 100kw/125kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 W |
| Number of Bearing | 1 |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
| Exciter Type | Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class | H class |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±1% |
| Specific Fuel Consumption | ≤ 202g / kw.h |
| Transient State Voltage | ≤-15%~+20% |
