| Specification | Prime Power | Standby Power |
|---|---|---|
| Rated Power (kVA) | 8 | 8 |
| Power Rating (kW) | 6 | 7 |
| Frequency (Hz) | 50 | |
| Engine Model | 3TNM72-GGE | |
| Engine Speed (RPM) | 1500 | |
| Phase | 3 | |
| PF | 0.8 | |
| Control System | Digital | |
| Rated Voltage (V) | 400/230 (According to customer requirements) | |
| Fuel Tank Capacity Operating Time | ≥ 8h @ 75% load | |
| Model | BYN8 (Open Type) | BYN8S (Silent Type) |
|---|---|---|
| Length (L) mm | 1400 | 1750 |
| Width (W) mm | 610 | 850 |
| Height (H) mm | 1130 | 1030 |
| Tank Capacity (L) | 14 | 14 |
| Engine Model & Manufacturer | 3TNM72-GGE (YANMAR) |
| Engine Type | 4 cycle, Inline, Water-cooled Diesel |
| No. of Cylinders - Bore × Stroke (mm) | 3 - φ72 × 74 |
| Combustion System | Indirect Injection |
| Compression Ratio | 23.5 |
| Displacement (liter) | 0.904 |
| Rated Output kW(PS) | 7.3/8.6 (9.9/11.7) |
| Continuous Rating kW(PS) | 6.6/7.8 (9.0/10.6) |
| Specific Fuel Consumption g/kW-h(g/PS-h) | max.265 (195) (at rated output) |
| Fuel Injection Timing (deg) | 17.0 (+1/-1) (FID b.T.D.C) |
| Engine Dry Weight (kg) | approx. 110 |
| Alternator Brand | BOBIG |
| Alternator Manufacturer | FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model | BW-164A |
| Alternator Rated Power | 6kw/8kva |
| Rated Voltage (V) | 230v/400v |
| Rated Frequency | 50hz |
| Connecting Type | 3 Phase and 4 Wire |
| Protection Grade | IP23 |
| Insulation Class | H class |
| Engine | Alternator | Fuel System | Generating Set |
|---|---|---|---|
| Water Jacket Preheater | PMG excitation | 12 / 24 hour base tank | Deepsea, ComAp, Smartgen etc. controller |
| Oil Preheater | Space heater | Bunded fuel tank | Trailer |
| Oil manual pump | Winding temperature measuring | External fuel tank | Tools with the machine |
| Automatic fuel feeding | |||
| Switch between external tank and base tank (three-way valve) |
